A3.5 Case (Pre-Order)

This page is for the Kickstarter Style All or Nothing Pre-Order. Charges will only be authorized, but not approved. If the goal is met and the project is successful, credit cards will be charged at the end of the campaign on September 9th. Note that this is special pre-order pricing and that prices will increase once the pre-order period is over.

This is an original case design that resembles my A3 case over at Alexander James Watches. After getting questions about them being compatible with the NH series, I got to work, sizing the case down in order to accommodate 28.5mm dials and the NH series of movements. While designing, I decided to make these a little more flexible with a secondary bezel to better accommodate thinner movements, the VH31 and Miyota 9xxx series. This page is for the case only. To order the bracelet, please visit this page.

The case has a 36mm diameter and is compatible with 28.5 mm dials.  This item comes with the crystal and bezel installed, caseback and gasket, and a crown.

Case specifications are below:

Case Material: 316L Stainless Steel
Finishing: Polished
Case Diameter: 36mm
NH Case Thickness: 11.3mm (with top hat style crystal included, 10.4mm without crystal)
Miyota / VH31 Case Thickness: 10.4mm (with flat crystal)
Lug to Lug Height: 43mm
Lug Width: 20mm
Caseback Screw down, solid , Polished Finish
Water Resistance 20ATM with proper assembly

Included:
- Installed crystal and bezel
- Matching caseback
- Gasket for caseback
- Selected Crown

Compatibility:
Seiko / NH Version:
- Seiko automatic movements: 7s26, 7s36, 7s25, 7s35, 6r15, 4r15, 4r35, 4r36 (and NH/NE equivalents)
- 28.5mm dials
- Crowns: AJuiceT DCSxxx and DCTxxx crowns and SKX013 Crowns
Note: These are designed for using the gray spacer that typically comes in Seiko movements like the NH35

Miyota 9xxx / VH31 Version:
- Miyota 9xxx Series, VH31
- 28.5mm dials
- Crowns: AJuiceT DCSxxx and DCTxxx crowns and SKX013 Crowns

A note to all non-US buyers, shipping will be charged at the time of shipment and import duty fees are not included.
